métier Click2CableDraw 1.01
Click2CableDraw is the easiest and fastest way to create cable drawings.
· With just a few clicks and a few keystrokes you get complete cable drawings
· Cables and single cores
· Color code according to DIN 47100
· Unshielded and shielded - both cabls and cores
· With and without shrinking tube
· Over 60 connectors available for connection to one or more cores
· Complete dimensioning of the cables - inclusive length, cross section ...etc.
· Each component can be assigned a manufacturer, article number ...etc.
· Drawing title block
· Bill of material
· Export of the drawing
Click2CableDraw will convince you!
Version 1.01 now with improved and sharper image display.
WHAT MAKES CLICK2CABLEDRAW SO SPECIAL
Intuitive user guidance
Just start working - there is a manual, but you can also get started immediately without it.
Wide range of functions
Although kept very simple, Click2CableDraw offers a huge range of functions.
No CAD knowledge required
Simply click.
